    Liquid Bottle Cardboard Tray Shrink Packaging Equipment For Beverage Line

    Ask Lasest Price
    Brand Name : Sunswell
    Model Number : MB
    Certification : CE SGS
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 10 sets/year
    Delivery Time : 60 days after receiving down payment
    • Product Details
    • Company Profile

    Liquid Bottle Cardboard Tray Shrink Packaging Equipment For Beverage Line


    PE Film Automatic Liquid Bottle Cardboard Tray Heat Shrink Wrapping Packing Machine


    Technical parameter

    1) Power supply. Total power : 380/220V ,75KW (three-phase )

    2) External gas source : 4-6kgf/cm2

    3) main motor: 380V 3300W

    4) Bottle separate electricity motor: 380V 820W*2

    5) Exit belt motor : 380V 750W

    6) Film cutting electricity motor :380V 820W

    7) Film feeding electricity motor: 3.3W

    8) Bottle entry plate chain electricity motor : 380V 1100W

    9) Whole bottle motor :380V 250W

    10) Machine size (L*W*H) :13500*1215*2150mm

    (Can make according to special requirement).

    11) ackage piece speed : 45package /minute

    12) Package product size : can according to client special requirement.

    13) Working platform height :L1150+50mm (can making according to special requirement).

    14) Conveyor belt : shanghai

    15) Usage film type : PE film and can use color film

    16) PE film width PE: according to client requirement , film thickness: 0.07mm-0.13mm;

    17) Film shrinkage ratio : length wise direction 70-80%, cross wise 20-30%.

    18) Circumstance condition: humidity 98%, temperature:20-40ºC.

    19) Noise: at working circumstance, noise 75DB.

    20) Whole machine all set safe protection device

    Main Electricity collocation list

    NoNameSpecificationNumberBrandPlace of origin
    1Touch screen10.7"1setSIEMENSGermany
    2Servo electric motor5set
    3Servo controller5set
    4PCC controlling system1pcs
    5Manipulation plate1pcs
    6Bus connector interfaceRS-232.1pcs
    7Input and output module6piece
    8PhotocellPEPPERL+FUCHS
    "P+F" "P+F"
    Germany
    9PneumaticsFESTOGermany
    10Gear box4pcsTransmission
    Equipment Co.,Ltd
    China
    11Force conveyor
    electricity motor
    2pcsTransmission
    Equipment Co.,Ltd
    China
    12Back Electricity shrink
    tunnel motor
    3pcsTransmission
    Equipment Co.,Ltd
    China
    13Weather belt2-3pcsHabsitSwiss
    14Frequency converterDANFOSSDenmark
    15Hot glue machineDynatecAmerica
    16BearingSKF or same
    Grade product
    Swiss
    17Linear bearingSKF or same
    Grade product
    Swiss
    18Synchronous belt1pcs
    19Pneumatic shaft/axis2pcsZhongguo HangtianChina
    20Conveyor chainShanghai lilaiChina
    21Electricity componentSchneiderFrance
